The Pacman Nebula in mapped color (NGC 281)

clic for 36% size 1288 x 934 (370 kB)

Clic here for a 60% size image 2147 x 1557 (912 kB)


About this Image

The Pacman Nebula (NGC 281) here in mapped color is a complex area of star formation in Cassiopeia. Prominent features include a small open cluster of stars, a diffuse red-glowing emission nebula, large lanes of dark obscuring gas and dust, and dense knots of dust and gas in which stars may still be forming. The open cluster of stars IC 1590 visible around the center has formed only in the last few million years.
The brightest member of this cluster is actually a multiple-star system shining light that helps ionize the nebula's gas, causing the bright glow visible throughout. The lanes of dust visible left of center are likely homes of future star formation. Dark Bok globules are visible against the bright nebula. The NGC 281 system is situated in a distance of about 10 thousand light years.
North is left.

Find a conventional (Ha)RGB version of this object: here.

Find a Hubble close-up of the central Bok globule here: 1.

Find a Kitt Peak 0,9m aperture widefield image here: 2.


Technical Details
Optics

16" cassegrain in secondary focus at f/10

Mount MK-100 GEM
Camera SBIG STL-11000M at -15-20C, internal filter wheel
Filters Baader RGB + S-II, Ha, O-III 7-8 nm
Date Aug 2008.
Location Wildon/Austria
Sky Conditions mag 5.5 sky, FWHM 1.5-2", temperature 13-20 C,
Exposure S-II:Ha:O-III= 600:480:480 min (30-minute sub-exposures);
R:G:B= 40:40:40 min (10-minute sub-exposures)
Programs used: Maxim DL 4.5; CCDstack; Fitsliberator; Photoshop CS3; Neatimage
